HP NetServer LXr Pro8 User Guide
Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
Contents 1 Setting Up the HP NetServer LXr Pro8........................................................1 Before You Set Up Your HP NetServer ..........................................................1 Setup Steps ...................................................................................................1 2 Controls, Indicators, and Ports ....................................................................5 Front Panel Controls ........................................................................
Removing a 128 MB SDRAM DIMM Module ................................................ 42 Installing the 4 GB Memory Board................................................................ 43 6 Installing Additional Boards....................................................................... 45 Introduction.................................................................................................. 45 Installing Accessory Boards .........................................................................
Setup Utility ................................................................................................. 75 Starting the Setup Utility .......................................................................... 75 Main Menu............................................................................................... 76 Using the Setup Screens.......................................................................... 76 Changing the Server Password ......................................................
Automated Fax ............................................................................................ 99 Telephone Support....................................................................................... 99 Obtaining HP Repair and Telephone Support............................................. 100 U.S. and Canada ................................................................................... 100 Europe.............................................................................................
Notice for Consumers in Australia .............................................................. 116 Notice For Consumers In New Zealand ...................................................... 116 Notice for Mexico: Hardware Warranty Statement...................................... 116 Póliza de Garantía ................................................................................. 117 Condiciones ........................................................................................... 117 Notas ........
1 Setting Up the HP NetServer LXr Pro8 Before You Set Up Your HP NetServer Before you set up your HP NetServer: • Read the Rack Installation Road Map for this HP NetServer. The Road Map shows how to set up the entire rack system. It will alert you to issues you must consider before installing the HP NetServer itself. • Read this chapter. This chapter tells how to set up and configure the HP NetServer LXr Pro8. It tells you what to do, and in what order.
Chapter 1 Setting Up the HP NetServer LXr Pro8 3. Store the empty boxes and packing material in a safe place. This is especially important if you plan to ship the HP NetServer elsewhere for final installation. 4. If you have options to add to the HP NetServer’s satellite chassis (memory, accessory boards, processor boards), remove the appropriate access panels from the satellite. (Refer to Chapter 3.) 5. Install additional memory or memory boards in the satellite chassis. (Refer to Chapter 5.) 6.
Chapter 1 Setting Up the HP NetServer LXr Pro8 13. Insert the Navigator CD-ROM, reboot, and check the Navigator README file for important installation information. (Refer to Chapter 9.) 14. Configure the HP NetServer with Configuration Assistant from the Navigator CD-ROM. Choose the Express Configuration option. (Refer to Chapter 9.) NOTE To fully configure the HP NetServer, all the rack components should be cabled and online (though not necessarily installed in the rack.) 15.
2 Controls, Indicators, and Ports Front Panel Controls Run Indicator DC Output Indicator AC Input Indicator Attention Indicator DC Power Switch Message Display Reset Switch Figure 2-1.
Chapter 2 Controls, Indicators, and Ports Table 2-1. Control Panel Switch and Indicator Definitions Control Description DC Power Switch Turns the system on, or returns it to standby. Reset Switch Press to perform a warm boot of the system. Run Indicator During system startup: lights green to indicated that the system passed the Power On Self Test and is starting to boot. During normal operation: should stay green continuously during normal operation to indicate that the BIOS is running.
Chapter 2 Controls, Indicators, and Ports Power Supply Indicators Each of the HP NetServer LXr Pro8's power supplies has these indicators: DC Output AC Input Indicator Indicator Attention Indicator Figure 2-2. Power Supply LEDs Table 2-2. Power Supply LEDs Control Description DC Output Indicator Green indicates that DC power is online. During normal operation, this LED should always be green. AC Input Indicator Green indicates that the power supply is receiving AC power.
Chapter 2 Controls, Indicators, and Ports Rear Panel Controls, Ports, and Indicators Serial Port A Serial Port B Mouse Port Keyboard Port I2C Connector Fan Pack Temperature Indicator Power Interlock Switch Parallel Port Ejector Handle Ejector Handle Fan Pack Temperature Indicator AC Power Plug Figure 2-3.
Chapter 2 Controls, Indicators, and Ports Table 2-3. Rear Panel Control and Indicator Definitions Control Description Power Interlock Switch This switch is mounted on the base chassis. When you turn this switch clockwise, you disable DC power and release the satellite chassis. You can then pull out the satellite chassis and open the satellite's top cover. Satellite Ejector Handles These handles are mounted on the satellite chassis. Use them to pull the satellite out from the base chassis.
Chapter 2 Controls, Indicators, and Ports Power-Up and Power-Down Procedures Power-Up Procedure 1. Make sure that the power interlock switch at the rear of the HP NetServer is in the locked position, and that AC power is connected. When the switch is locked, the slot through the middle of the switch is vertical. See Figure 2-4. ◊ If the power interlock switch was unlocked, the system starts as soon as you relock the switch if AC power is connected. Skip ahead to step 3.
Chapter 2 Controls, Indicators, and Ports 2. Press the DC power button on the HP NetServer's control panel. The system now powers up. DC Power Figure 2-5. HP NetServer LXr Pro8 Control Panel 3. Turn on the monitor. Power Down Procedure 1. Log off all users. Shut down all networking software and applications. 2. Press the DC power switch on the HP NetServer's control panel (Figure 2-5). Normally, this is the complete procedure. 3.
Chapter 2 Controls, Indicators, and Ports If powering down the system for service, turn the power interlock switch to this position. Figure 2-6. Power Interlock Switch in Unlocked Position NOTE After you unlock the power interlock switch, DC power is turned off for all components within the satellite chassis except for five volts at the system control board, which is located on the SCSI extender tray in the bottom of the system's lower board cage.
Chapter 2 Controls, Indicators, and Ports When preparing your site for installation, allow for the additional inrush current. Since maximum inrush current for the HP NetServer LXr Pro8 is 80 amps for more than 10ms, the following circuit breaker recommendations need to be followed before installing the server in your environment: • In North American, a 20-amp-minimum circuit is to be used with one NEMA AB1 class 14B breaker for each 16-amp PDU.
3 Opening and Closing the HP NetServer Multiple Points of Access The HP NetServer LXr Pro8 is designed for easy access to all components. It features a satellite chassis which you can extend or detach from the main chassis for servicing. The satellite chassis contains the HP NetServer’s logic and memory boards. These boards are installed in two card cages, each with its own access route. The main chassis, or base chassis, holds the power supplies, control panel, and mass storage.
Chapter 3 Opening and Closing the HP NetServer Figure 3-1. Removing the HP NetServer’s Front Bezel To replace the front bezel: 1. Hold it up in front of the HP NetServer. Press the bezel’s bottom edge against the server. Make sure that the bottom of the bezel hooks under the two metal tabs mounted on the front of the server. 2. Firmly press the top of the bezel onto the front of the HP NetServer until you hear a click.
Chapter 3 Opening and Closing the HP NetServer NOTE If the HP NetServer is mounted in the rack at an awkward height, it may be easier and safer to completely detach the satellite from the base and carry it elsewhere for service. See the next section for details. NOTE The satellite chassis' top cover will not open until you slide out the satellite chassis. To extend the satellite chassis for service: 1. Log off all users. Shut down all networking software and applications, if running. 2.
Chapter 3 Opening and Closing the HP NetServer Figure 3-2. Location of the Retention Bracket 5. Stand behind the HP NetServer and grasp the two ejector handles on the HP NetServer's rear panel. Pull both handles down firmly, and then pull the satellite toward you. Pull it out until its slides are fully extended. The slides lock in the extended position, so that the satellite cannot move while you service it.
Chapter 3 Opening and Closing the HP NetServer Ejector Handles Figure 3-3. Sliding Out the Satellite Chassis Redocking the Satellite Chassis 1. When you finish servicing the HP NetServer, move to the front of the server and unlatch all four power supplies. (If the front bezel is in place, remove it. See "Removing and Replacing the Front Bezel." 2. At the rear, insert the satellite chassis. To do so, push in the release latch for each slide (Figure 3-4).
Chapter 3 Opening and Closing the HP NetServer Push down the release latches on each slide. Then push the satellite partly onto the base chassis. Release Latch Figure 3-4. Unlocking the Slides If you do not depress these two latches, the satellite cannot move all the way onto the base chassis. 3. Let go of the release latches. Grasp the ejector handles and push the satellite chassis the rest of the way onto the base. Be careful to keep the ejector handles in the "down" position. 4.
Chapter 3 Opening and Closing the HP NetServer Detaching and Reattaching the Satellite Chassis You will sometimes need to detach the satellite chassis from the base chassis completely. You would do this because: • You need to move the HP NetServer or mount it in a rack. The HP NetServer LXr Pro8 is very heavy. For safety, detach the satellite from the base and carry each component separately.
Chapter 3 Opening and Closing the HP NetServer 7. Both people must carefully pull the satellite chassis off the slides (Figure 3-5). Place the satellite carefully on a nearby work surface. Figure 3-5. Pulling the Satellite Chassis Off Its Slides 8. To replace the satellite chassis, move to the front of the server and unlatch all four power supplies. (If the front bezel is in place, remove it. See "Removing and Replacing the Front Bezel.
Chapter 3 Opening and Closing the HP NetServer 9. Two people can now lift the satellite chassis and mount it on the slides. A rail is mounted on each side of the satellite, near the bottom. As you begin to push the satellite back onto the slides, make sure to fit these rails inside the slides (Figure 3-6). Release Latch Slide Rail on side of satellite Fit rail inside slide Figure 3-6. Replacing the Satellite on Its Slides 10. Push the satellite chassis onto the slides.
Chapter 3 NOTE Opening and Closing the HP NetServer If the satellite refuses to slide all the way forward, check that you have placed it correctly on its slides. Also make sure that you pressed in the release levers on both slides. 12. Replace the retention bracket as shown in Figure 3-2. 13. Relock the power interlock switch on the HP NetServer's rear panel. To do this, turn the switch counter-clockwise as far as it will go. 14. At the front, relatch the power supplies.
Chapter 3 Opening and Closing the HP NetServer 1. Insert finger in each fingerhold. Push fingerholds toward each other. 2. Push cover forward until it stops, then lift cover by fingerholds. Figure 3-7. Unlatching HP NetServer's Top Cover 4. Maintain the pressure with your fingers and slide the cover away from you. The cover slides about one-half inch before stopping. See Figure 3-7. 5. Lift the rear of the cover by the fingerholds. The cover swings open on its hinges. 6.
Chapter 3 Opening and Closing the HP NetServer Spring-loaded hinge pins Figure 3-8. Top Cover in Open Position 7. When the NetServer is mounted in a rack, adjacent components can block the cover from opening fully. If this happens, remove the cover entirely: a. Swing open the cover as far as possible. b. Pull back one of the spring-loaded hinge pins on the underside of the cover. See Figure 3-8. c. Lift the cover off. d.
Chapter 3 Opening and Closing the HP NetServer 8. To close the satellite chassis' top cover: a. Swing the cover back down. b. Insert your fingers in the fingerholds again and push inward. c. While maintaining finger pressure in the fingerholds, slide the cover about one-half inch toward the rear of the chassis, to lock the cover closed. d. Release the fingerholds.
Chapter 3 Opening and Closing the HP NetServer 3. Remove the HP NetServer's rear access panel: a. Loosen the three captive screws that fix the panel in place. See Figure 3-10. b. Lift off the panel. Mounting Tab Captive Screws Mounting Tab Figure 3-10. Removing the Rear Access Panel 4. The lower board cage is now exposed. Remove or add boards as needed, then reattach the rear access panel: a. Lower the panel into place. A slotted flange extends from the top of the panel on either side.
4 Installing Mass Storage Types of Devices That Can Be Installed The HP NetServer LXr Pro8 can accept several common tray internal mass storage devices. The devices fit in bays in the HP NetServer’s front panel. The common tray area can hold up to three 4-gigabyte or 9-gigabyte hard disk drives, or one hard disk drive and an internal tape device. The HP NetServer supports Fast/Wide SCSI for internal devices. Ultra-SCSI devices, if installed, run as Fast/Wide devices.
Chapter 4 Installing Mass Storage NOTE You can change the default boot order during system startup. See "Boot Menu" in Chapter 9. Setting the Device's SCSI Device ID When installing internal hard drives in the HP NetServer: • Set the boot drive's SCSI device ID to 0 • Set the SCSI device ID of the second drive (if any) to 1 • Set the SCSI device ID of the third drive (if any) to 2 Drive 0 is the boot drive, unless you boot from the floppy diskette drive or CD-ROM.
Chapter 4 Installing Mass Storage • Remove the drive's termination jumper. (The SCSI cable to the internal drives is terminated.) For instructions, refer to the disk drive's installation guide. 3. Choose the drive bay that the device will occupy. Remove the filler panel that covers the bay. 4. Reach into the bay and pull out the data communication cable and a power cable. The three drive bays are served by one SCSI data cable with several connectors, and by several free power cables.
Chapter 4 Installing Mass Storage 6. Slide the drive all the way back into the bay. The flanges at the top and bottom of the drive tray should be flat against the server's chassis. The mounting holes in each flange should line up with matching holes in the chassis. 7. Fasten each flange against the chassis with screws. 8. If installing a second drive, repeat steps 2 through 6. 9. When finished, reattach the front bezel.
Chapter 4 Installing Mass Storage 1. Connect cables to first drive and push it completely into the server. 2. Connect cables to second drive, but push it only partway into server. 3. Connect cables to third drive, and push it part-way into server. Then, push both the second and third drives the rest of the way in. Figure 4-2. Installing Three Hard Disk Drives Since you did not fully insert the second drive, it does not push the SCSI data cable back into the server.
Chapter 4 Installing Mass Storage 5. Push the third drive part-way into its bay. Then slide the second and third drives, together, all the way back into the server. Fasten the drives in place with screws. NOTE 34 If you already have two drives in the server and are adding a third, unfasten the retaining screws on the drive that is adjacent to the empty drive bay. Pull the drive half-way out. Then begin at Step 4.
5 Installing Additional Memory Introduction This chapter includes guidelines and instructions for: • Removing and reinstalling the HP NetServer's 4 GB memory board for a memory upgrade • Installing 128 MB SDRAM DIMMs in the specified interleave configuration on the 4 GB memory board • Removing 128 MB SDRAM DIMMs and downsizing the memory configuration For more information on the memory board, refer to the HP NetServer LXr Pro8 4 GB Memory Board Installation Guide.
Chapter 5 Installing Additional Memory • The recommended memory configurations and the slot numbers where SDRAM DIMMs are installed are listed in Figure 5-2 and Figure 5-3. Add SDRAM DIMMs only in these quantities and in the specified slot numbers. Figure 5-1 shows the DIMM slot numbers on the 4 GB Memory Board. M0 M4 M8 M12 M16 M20 M24 M28 Figure 5-1. DIMM Slot Numbers Figure 5-2 shows memory configurations when one 4 GB Memory board is installed.
Chapter 5 Installing Additional Memory Memory Upper Memory Board Slots M0 - M31 Size Quan -tity 0 4 8 12 16 20 24 28 256 MB 2 X X 512 MB 4 X X X X 1 GB 8 X X X X X X X X 1.5 GB 12 XXX XXX XXX XXX 2 GB 16 XX XX XX XX XX XX XX XX 3 GB 24 XXX XXX XXX XXX XXX XXX XXX XXX 4 GB 32 XXXX XXXX XXXX XXXX XXXX XXXX XXXX XXXX Figure 5-2.
Chapter 5 Installing Additional Memory Tools Required To remove or install a memory board, first remove the satellite chassis lower fan module and the rear access panel. These tools are required for removal and installation of accessories: • Number 1 Phillips head screwdriver • An anti-static service kit (3M 8501/8502/8503 or equivalent). This kit includes a static-dissipating work surface, a chassis clip lead, and a wrist strap.
Chapter 5 Installing Additional Memory Base Chassis Satellite Chassis 4 GB Memory Board Retaining Clips Figure 5-4. Removing the Memory Board 5. Hold the memory board by the corners, and carefully pull the board from its slot until the edge connectors are free of the system board connectors. 6. Place the memory board component-side up on a firm, anti-static surface for protection.
Chapter 5 Installing Additional Memory Installing 128 MB SDRAM DIMMs on the 4 GB Memory Board Follow these steps to install a 128 MB SDRAM DIMM in a slot on the 4 GB memory board. CAUTION Use only 128 MB SDRAM DIMMs acquired from HP. Contact HP Customer Support for a list of qualified 128 MB SDRAM DIMMs. HP will not support configurations that use non-HP SDRAM DIMMs. 1. If you are installing a new memory board, remove the 4 GB memory board from its anti-static container. 2.
