HP xw8600 and xw9400 Workstations - Nvidia Quadro FX5800 graphics card and auxiliary power adapter cable installation
Table Of Contents
- Nvidia Quadro FX5800 graphics card and auxiliary power adapter cable installation
- Introduction
- Kit contents
- Before you begin
- Warnings and cautions
- Step 1—Preparing the workstation
- Step 2—Installing the front PCI fan in the HP xw8600 Workstation
- Step 3—Installing the FX5800 graphics card
- Step 4—Installing the auxiliary power adapter cable
- Step 5—Installing the card support
- Step 6—Reassembling the workstation
- Step 7—Configuring the software
CAUTION: To prevent damage to the workstation, observe the following Electrostatic Discharge
(ESD) precautions while performing the system parts removal and replacement procedures:
— Work on a static-free mat.
— Wear a static strap to ensure that any accumulated electrostatic charge is discharged from your body
to the ground.
— Create a common ground for the equipment you are working on by connecting the static-free mat,
static strap, and peripheral units to that piece of equipment.
NOTE: HP accessories are for use in HP Workstation products. They have been extensively tested
for reliability and are manufactured to high quality standards.
ENWW Warnings and cautions 3
