HP Notebook Projection Companion - Service Manual

12
4
Loosen the three screws
J1635-3177-00*3 for moving
Bottom Cover.
5
Loosen the three screws
J1635-2021-00*2 to remove
the DC Fan J2394-0103-00.
6
Loosen J1635-3184-00*1.
7
1. Loosen J1635-3177-00*3.
2. Remove all the wires on
the Main board.
3. Remove Main board.
J1635-3177-00*3
J1635-3177-00*3
J1635-2021-00*2
J1635-3184-00*1
