Port Status and Configuration
Viewing Port Status and Configuring Port Parameters
ProCurve(config)# show interfaces config
Port Settings
Port Type | Enabled Mode Flow Ctrl MDI
----- --------- + ------- ------------ --------- ----
1 10/100TX | Yes Auto-10-100 Disable Auto
2 10/100TX | Yes Auto Disable Auto
3 10/100TX | Yes Auto Disable Auto
4 10/100TX | Yes Auto Disable Auto
5 10/100TX | Yes Auto Disable Auto
6 10/100TX | Yes Auto Disable Auto
Figure 10-4. Example of a show interfaces config Command Listing
The display option can be used to initiate the dynamic update of the show
interfaces command with the output being the same as the show interfaces
command. When using the display option in the CLI, the information stays on
the screen and is updated every 3 seconds, as occurs with the display using
the menu feature. The update is terminated with Cntl-C.
You can use the arrow keys to scroll through the screen when the output does
not fit in one screen.
Syntax: show int display
Initiates the dynamic update of a command. The output is the
same as the equivalent “show” command.The information is
updated every 3 seconds.
Note: Select “Back” to exit the display.
For example:
ProCurve# show int display
10-10
