Getting Started
Sources for More Information
Keys
Simulations of actual keys use a bold, sans-serif typeface with square brackets.
For example, the Tab key appears as
[Tab] and the “Y” key appears as [Y].
Sources for More Information
For information about switch operation and features not covered in this guide,
consult the following sources:
■ Feature Index—For information on which manual to consult for a given
software feature, refer to the “Software Feature Index” on page xii.
Note For the latest version of all ProCurve switch documentation referred to below,
including Release Notes covering recently added features, visit the ProCurve
Networking web site at www.procurve.com, click on Support, and then click
on Manuals.
■ Software Release Notes—Release Notes are posted on the ProCurve
Networking web site and provide information on new software updates:
• new features and how to configure and use them
• software management, including downloading software to the switch
• software fixes addressed in current and previous releases
■ Product Notes and Software Update Information—The printed Read Me
First shipped with your switch provides software update information,
product notes, and other information.
■ Installation and Getting Started Guide—Use the Installation and Get-
ting Started Guide to prepare for and perform the physical installation.
This guide also steps you through connecting the switch to your network
and assigning IP addressing, as well as describing the LED indications for
correct operation and trouble analysis.
■ Management and Configuration Guide—Use this guide for information
on topics such as:
• various interfaces available on the switch
• memory and configuration operation
• interface access
• IP addressing
• time protocols
