Troubleshooting
Unusual Network Activity
Figure C-2. Displaying Encryption Keys
Global RADIUS Encryption Key
Unique RADIUS Encryption Key
for the RADIUS server at
10.33.18.119
Also, ensure that the switch port used to access the RADIUS server is not
blocked by an 802.1X configuration on that port. For example, show port-
access authenticator < port-list > gives you the status for the specified ports.
Also, ensure that other factors, such as port security or any 802.1X configura-
tion on the RADIUS server are not blocking the link.
The authorized MAC address on a port that is configured for both
802.1X and port security either changes or is re-acquired after
execution of aaa port-access authenticator < port-list > initialize. If the port is
force-authorized with aaa port-access authenticator <port-list> control authorized
command and port security is enabled on the port, then executing initialize
causes the port to clear the learned address and learn a new address from the
first packet it receives after you execute initialize.
A trunked port configured for 802.1X is blocked. If you are using
RADIUS authentication and the RADIUS server specifies a VLAN for the port,
the switch allows authentication, but blocks the port. To eliminate this
problem, either remove the port from the trunk or reconfigure the RADIUS
server to avoid specifying a VLAN.
QoS-Related Problems
Loss of communication when using VLAN-tagged traffic. If you cannot
communicate with a device in a tagged VLAN environment, ensure that the
device either supports VLAN tagged traffic or is connected to a VLAN port that
is configured as
Untagged.
C-13
