Specifications

Server component identification 42
System LED and Color
Internal Health
LED Color
Status
Processor failure,
socket X (Amber)
Red One or more of the following conditions may exist:
• Processor in socket X has failed.
• Processor in socket X failed over to the second processor.
• Processor X is not installed in the socket.
• Processor X is not supported.
• Processor heatsink is not attached properly.
Amber Processor in socket X is in a pre-failure condition.
Processor failure, both
sockets (Amber)
Red Processor types are mismatched.
PPM failure (Amber) Red • PPM has failed.
• PPM is not installed, but the corresponding processor is
installed.
DIMM failure, slot X
(Amber)
Red • DIMM in slot X has failed.
• DIMM in slot X is an unsupported type, and no valid
memory exists in another bank.
Amber
• DIMM in slot X has reached single-bit correctable error
threshold.
• DIMM in slot X is in a pre-failure condition.
• DIMM in slot X is an unsupported type, but valid memory
exists in another bank.
Overtemperature
(Amber)
Red
• The Health Driver has detected a cautionary temperature
level.
• The server has detected a hardware critical temperature
level.
Fan (Amber) Red
The minimum fan requirements are not being met. Fan has
failed.
Amber
A fan has failed but still meets the minimum fan requirements
(with redundant system fan option only).
