Specifications

Specifications 48
Specification Value
Input requirements
Rated input voltage 100 VAC to 240 VAC
Rated input frequency 47 Hz to 63 Hz
Rated input current 7.8 A (110 V) to 3.9 A (220 V)
Rated input power 710 W
BTUs per hour 2425
Power supply output Specification
Rated steady-state power 460 W
Maximum peak power 484 W
Hot-plug power supply calculations
For hot-plug power supply specifications and calculators to determine electrical and heat loading for the
server, refer to the HP Enterprise Configurator website (http://h30099.www3.hp.com/configurator/
).
DDR SDRAM DIMM specifications
NOTE: Use only 256-MB, 512-MB, 1-GB, 72-bit wide, 2.5-B, PC2100 Registered ECC DDR SDRAM. Use
Compaq branded or HP DDR SDRAM only.
Item Description
Size 256 MB, 512 MB, 1 GB, 2 GB
Width 72 bits
Upgrade requirement
Any combination of like-paired DDR SDRAM DIMMs
that provide a minimum of 512 MB
1.44-MB diskette drive specifications
Specification Value
Dimensions
Height 12.7 mm (0.5 in)
Width 96 mm (3.8 in)
Depth 130 mm (5.1 in)
LEDs (front panel) Green = On
Read/write capacity per
diskette
High density 1.44 MB
Low density 720 KB
Drives supported 1
Drive height One-third height
Drive rotation 300 rpm
Transfer rate
