Nvidia Quadro FX5800 graphics card and auxiliary power adapter cable installation

Nvidia Quadro FX5800 graphics card and

auxiliary power adapter cable installation

Introduction

This document describes how to install an Nvidia Quadro FX5800 graphics card and an auxiliary power

adapter cable in HP xw8600 Workstations and HP xw9400 Workstations.

Kit contents

●

FX5800 graphics card

●

Auxiliary power adapter cable

●

Card support bracket

●

Fan for HP xw8600 Workstation

●

Warranty

Before you begin

Visit http://www.hp.com/go/productbulletin to view QuickSpecs and determine the compatibility of this

product with your HP workstation.

Before installing an Nvidia FX5800 Quadro graphics card, ensure the following criteria are met:

●

System must contain a 1050 Watt power supply minimum.

●

System memory cannot exceed 32 GB with dual FX5800 cards (HP xw8600 Workstation).

●

System cannot contain Dual FSB1600/ Quad core processors with dual FX5800 cards (HP xw8600

Workstation).

trademark of Hewlett-Packard Development Company, L.P. Printed in the U.S.

ENWW Introduction 1
