HP supports, on select HP ProLiant servers, computational accelerator modules based on NVIDIA® Tesla™ and NVIDIA® GRID™ Graphical

Processing Unit (GPU) technology.

The following Tesla Modules are available from HP, for use in certain HP SL-series servers.

NVIDIA Tesla K10 Dual GPU PCIe Module

NVIDIA Tesla K10 Rev B Dual GPU Module

NVIDIA Tesla K20 5 GB Module

NVIDIA Tesla K20X 6 GB Module

NVIDIA Tesla K40 12 GB Module

NVIDIA GRID K2 PCIe GPU Kit

The NVIDIA GRID K2 PCIe GPU Kit can also be used in HP ProLiant WS460c workstation blades.

Based on NVIDIA's CUDA™ architecture, the Tesla and GRID Modules enable seamless integration of GPU computing with HP ProLiant

servers for high-performance computing and large data center, scale-out deployments. These Tesla and GRID Modules deliver all of

the standard benefits of GPU computing while enabling maximum reliability and tight integration with system monitoring and

management tools such as HP Insight Cluster Management Utility. The GRID K2 uses the NVIDIA Kepler GPU architecture to provide

NVIDIA Quadro® professional-class visualization for graphics intensive applications and for virtual desktop environments.

The GRID K2 uses the NVIDIA Kepler GPU architecture that combines Tesla's high performance computing - found in other Tesla

Modules - and the NVIDIA Quadro® professional-class visualization in the same GPU. The GRID K2 is the ideal solution for customers

who want to deploy high performance computing in addition to advanced and remote visualization in the same datacenter.

The HP GPU Ecosystem includes HP Cluster Platform specification and qualification, HP-supported GPU-aware cluster software, and

also third-party GPU-aware cluster software for NVIDIA Tesla and GRID Modules on HP ProLiant Servers. In particular, the HP Insight

Cluster Management Utility (CMU) will monitor and display GPU health sensors such as temperature. Insight CMU will also install and

provision the GPU drivers and the CUDA software. Insight CMU is integrated with popular schedulers such as Adaptive Moab, Altair PBS

Professional, and IBM Platform LSF - all of which have the capability of scheduling jobs based on GPU requirements.

NVIDIA K10, K2

NVIDIA K20, K20X, K40

What's New

Support for the NVIDIA Tesla K40 12 GB Module

QuickSpecs

NVIDIA Accelerators for HP ProLiant Servers

Overview

DA - 14576 Worldwide — Version 3 — December 9, 2013

Page 1

Summary of content (11 pages)

PAGE 1
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Overview HP supports, on select HP ProLiant servers, computational accelerator modules based on NVIDIA® Tesla™ and NVIDIA® GRID™ Graphical Processing Unit (GPU) technology. The following Tesla Modules are available from HP, for use in certain HP SL-series servers.
PAGE 2
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Models NVIDIA Passive Tesla Modules NVIDIA GRID K2 Dual GPU PCIe Graphics Accelerator NOTE: 2-slot passively cooled GRID module with 8 GB memory. NOTE: Please see the HP ProLiant SL250s and SL270s Gen8 server QuickSpecs or HP ProLiant WS460c Generation 8 Workstation Blade QuickSpecs for configuration rules including requirements, if any, for enablement kits. http://h18004.www1.hp.com/products/quickspecs/14232_div/14232_div.html http://h18004.www1.hp.
PAGE 3
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Standard Features K2, K10, K20, K20X and K40 Modules Performance of the K2 Module 3072 CUDA cores (1536 per GPU) GDDR5 memory optimizes performance and reduces data transfers by keeping large data sets in 8 GB of local memory, 4 GB attached directly to each GPU. The Kepler GPU includes a high-performance H.264 encoding engine capable of encoding simultaneous streams with superior quality.
PAGE 4
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Standard Features attached to the GPU The NVIDIA Parallel DataCache™ accelerates algorithms such as physics solvers, ray-tracing, and sparse matrix multiplication where data addresses are not known beforehand. This includes a configurable L1 cache per Streaming Multiprocessor block and a unified L2 cache for all of the processor cores.
PAGE 5
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Standard Features in real time, can be stored for historical analysis and can be easily used to set up management alerts. Supported Operating Systems NOTE: The NVIDIA Tesla and GRID modules are supported only on 64-bit versions of Linux and Windows operating systems. The supported operating systems are those below.
PAGE 6
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Optional Features HP High Performance Clusters HP Cluster Platforms HP HPC Interconnects HP Insight Cluster Management Utility Third Party GPU Cluster and Development Software HP Cluster Platforms are specifically engineered, factory-integrated largescale ProLiant clusters optimized for High Performance Computing, with a choice of servers, networks and software.
PAGE 7
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Optional Features Service and Support HP Technology Services for ProLiant Servers Capitalizing on HP ProLiant server capabilities requires a service partner who understands your increasingly complex business technology environment. That's why it makes sense to team up with the people who know HP infrastructure hardware and software best - the experienced professionals at HP Services.
PAGE 8
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Optional Features Related Services HP Proactive Care Personalized Support - Environmental Option The Personalized Support option provides an assigned Account Support Manager who can bring best practices from across the industry plus extra technical skills to your IT team. This option is only available as an add-on to HP Proactive Care Support.
PAGE 9
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Related Options HP High Performance Cluster Models HP Insight Cluster Management Utility 1yr 24x7 Flexible License NOTE: This part number can be used to purchase one certificate for multiple licenses with a single activation key. Each license is for one node (server). Customer will receive a printed end user license agreement and license entitlement certificate via physical shipment.
PAGE 10
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Technical Specifications Form Factor 10.7 in (27.2 cm) PCIe x16 form factor Number of Tesla GPUs Tesla K20, K20X, K40 1 GPU Tesla K10, GRID K2 2 GPUs Double Precision floating Tesla K10 point performance (peak) Tesla K20 1.32 Tflops Tesla K40 1.43 Tflops System Interface Thermal Solution 4.577 Tflops (2.288 Tflops per GPU) 3.52 Tflops Tesla K20X 3.95 Tflops Tesla K40 4.29 Tflops Total Dedicated Memory Tesla K20X Power Consumption 1.
PAGE 11
QuickSpecs NVIDIA Accelerators for HP ProLiant Servers Technical Specifications Environment-friendly Products and Approach End-of-life Management Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: and Recycling http://www.hp.com/go/green. To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest HP sales office.
