HP ENVY Notebook Intel Models 17-n100 17-n199 3D camera Models 17-r100 17-r199 (worldwide) 3D camera Models m7-r100 m7-r199 (North America) - Maintenance and Service Guide
Table Of Contents
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Component replacement procedures
- Bottom cover
- Hard drive
- WLAN module
- Memory module
- USB board
- Fan
- Heat sink
- RTC battery
- Speakers (front)
- Subwoofer
- System board
- Solid State Drive
- Speaker (rear)
- LID board
- TouchPad assembly
- Fingerprint reader board (select products only)
- Power connector cable
- Display assembly – touch screen
- Display assembly – non-touch screen
- Component replacement procedures
- Computer Setup (BIOS), TPM, and HP Sure Start – Windows 10
- Using Setup Utility (BIOS) in Windows 8.1
- Using Setup Utility (BIOS) in Windows 7
- HP PC Hardware Diagnostics (UEFI) – Windows 10
- Using HP PC Hardware Diagnostics (UEFI) in Windows 8.1
- Backup and recovery – Windows 10
- Backing up, restoring, and recovering in Windows 8.1
- Backing up, restoring, and recovering in Windows 7
- Ubuntu Linux – Backing up, restoring, and recovering
- Specifications
- Power cord set requirements
- Recycling
- Index
Category Description
Supports Voice Recognition
Intel RealSense 3D camera - activity LED, USB 3.0
1080p by 30 frames per second
4x depth resolution, 480x640
85° diagnal eld of view
Dual array Digital Microphones with software
Windows Hello
Enable HP Noise Cancellation
Supports Voice Recognition
Audio Bang & Olufsen
Quad speakers
Subwoofer
Ethernet Integrated 10/100/1000 network interface card (NIC)
Sensor Accelerometer (for hard drive protection support)
Wireless networking Integrated Wireless options with dual antenna (M.2/PCIe):
●
Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + Bluetooth 4.0 Combo Adapter
●
Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + Bluetooth 4.0 Combo Adapter
●
Intel Dual Band Wireless-AC 7265 802.11 ac 2x2 WiFi + Bluetooth 4.0 Combo Adapter
●
Igntel Dual Band Wireless-AC 7265BN 802.11 b/g/n 2x2 WiFi + Bluetooth 4.0 Combo Adapter
●
Realtek RTL8723BE 802.11b/g/n 1x1 Wi-Fi + Bluetooth 4.0 Combo Adapter
Compatible with Miracast-certied devices
Connected Standby support
External media cards HP Multi-Format Digital Media Card Reader
Supports SD/SDHC/SDXC
Push-Push Insertion/Removal
Internal card expansion One M.2 slot for WLAN
One M.2 slot for SSD
Ports HDMI version 1.4 supporting 1920 ×1200 @ 60 Hz
Hot Plug/unplug and auto detect for correct output to wide-aspect vs. standard aspect video
AC Smart Pin adapter plug
Headphone/microphone combo jack
RJ-45 (Ethernet)
USB 3.0 ports (two on left side, two on right side)
Keyboard/pointing devices Full size keyboard with numeric keypad
Touchpad requirements:
●
Clickpad with image sensor
3
