Category Description
●
Multitouch gestures enabled (default on: 2-nger scroll, pinch, rotate, 2-nger click, 3-nger
ick)
●
Support Windows 10 Modern Trackpad Gestures
●
Taps enabled as default
Power requirements AC adapters:
AC Adapter 65-W Smart nPFC, 3 pin, RC 4.5mm connector (models with discrete graphics only)
AC Adapter 65-W EM Smart nPFC, 3 pin, RC 4.5mm connector (models with discrete graphics in
India/China only)
AC Adapter 90-W Smart nPFC, 3 pin, RC 4.5mm connector (models with discrete graphics only)
AC Adapter 120-W 3 pin, 4.5 mm connector
1 meter power cord
Battery:
4-cell, 41-Whr, 2.2Ah, li-ion battery
6-cell battery - 62 Whr (2.8 Ah)
Security Support for the following:
●
Security Lock
●
Fingerprint Reader (optional —m7 branding no support). ) with software support (HP Simple
Pass)
Operating system Preinstalled:
Microsoft Windows 10 Standard
FreeDos 2.0 only support non-touch and non-3D Camera
Serviceability
●
AC adapter
●
Battery
●
Optical drive
