HP ENVY Notebook Intel Models 17-n100 17-n199 3D camera Models 17-r100 17-r199 (worldwide) 3D camera Models m7-r100 m7-r199 (North America) - Maintenance and Service Guide

Component Description
(1) Power light
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a power-
saving state. The computer shuts o power to the display
and other unneeded components.
●
O: The computer is o or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.
(2) Mute light
●
Amber: Computer sound is o.
●
O: Computer sound is on.
(3) Fingerprint reader light (select products only) Allows a ngerprint logon to Windows, instead of a password.
●
White: The ngerprint was read
●
Amber: The ngerprint was not read
(4) Caps lock light On: Caps lock is on, which switches the keys to all capital letters.
Buttons, speakers, and ngerprint reader (select products only)
Component Description
(1) Power button
●
When the computer is o, press the button to turn on the
computer.
●
When the computer is on, press the button briey to
initiate Sleep.
●
When the computer is in the Sleep state, press the button
briey to exit Sleep.
●
When the computer is in Hibernation, press the button
briey to exit Hibernation.
10 Chapter 2 External component identication
