Item Component Spare part number
(1) Display assembly (includes webcam/microphone module and wireless antenna cables). For display components part
numbers, see Display assembly subcomponents – touch screen on page 19 or see Display assembly subcomponents –
non-touch screen on page 20.
(2) Top cover with keyboard
For use in the United States 813678–001
For use in the United Kingdom 813678–031
For use in Belgium 813678-A41
For use in the Czech Republic and Slovakia 813678-FL1
For use in Denmark, Finland, and Norway 813678-DH1
For use in French Canada 813678-DB1
For use in France 813678-051
For use in Germany 813678-041
For use in Italy 813678-061
For use in the Netherlands 813678-B31
For use in Portugal 813678-131
For use in Russia 813678-251
For use in Saudi Arabia 813678-171
For use in Spain 813678-071
For use in Slovenia 813678-BA1
For use in Switzerland 813678-BG1
For use in Turkey 813678-141
For use in Latin America 813678-161
For use in Japan 813678-291
For use in South Korea 813678-AD1
Black for use in the United States 818093-001
(3) TouchPad assembly 818095-001
(4) Touchpad support bracket 818091-001
TouchPad cable 818087-001
(5) LID software board 813897-001
LID software board cable 823506-001
(6) Power connector cable kit 813804-001
Power connector 813797-001
(7) Speaker Kit rear speaker 813806-001
(8) Speaker Kit front speaker 813805-001
(9) Subwoofer 813807-001
16 Chapter 3 Illustrated parts catalog
