Item Component Spare part number
(10) USB board 813794-001
USB board cables 813793-001
(11) System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Without the Windows operating system
xxxxxx-501: Windows 8.1 Standard
xxxxxx-601: Windows 10
Intel Core i7-5500U processor 940M 2 GB 813681-xxx
Intel Core i7-5200U discrete processor 940M 2 GB 813680-xxx
Intel Core i7-5500U processor 950M 2 GB 813682–xxx
Intel Core i5-6200U processor 940M 2 GB 829065-xx1
Intel Core i7-6700HQ processor 950M 4 GB 829066-xx1
Intel Core i7-6700HQ processor 950M 4 GB 3D camera 829068-xx1
Intel Core i7-6700HQ processor 940M 4 GB 3D camera 829069-xx1
Intel Core i7-6500U processor 940M 2 GB 829070-xx1
Intel Core i7-6500U processor 940M 2 GB 3D camera 837769-xx1
(12) Memory module (PC3L-1600)
8-GB 693374-005
4-GB 691740-005
(13) RTC battery 759981-001
(14) WLAN module
Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + Bluetooth 4.0 Combo Adapter 784644-005
Realtek RTL8723BE 802.11b/g/n 1x1 Wi-Fi + Bluetooth 4.0 Combo Adapter 792610-005
Intel Dual Band Wireless-AC 7265 802.11 ac 2x2 WiFi + Bluetooth 4.0 Combo Adapter (non
vPRO)
793840-005
Intel Dual Band Wireless-N 7265BN 802.11 b/g/n 2x2 WiFi + Bluetooth 4.0 combo adaptor 793843-005
Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + Bluetooth 4.0 Combo Adapter 806723-005
(15) Heat sink (includes replacement thermal material):
Discrete 25 W 813799-001
Discrete 40 W 813800-001
Discrete 30 W 832355-001
Thermal pad 3D camera 832359-001
(16) Fan (includes cable) 813798-001
(17) Hard drive connector cable (For a full list of Hard drive components, see Mass storage
devices on page 18.):
813795-001
Computer major components 17
