Item Component Spare part number
(7) Display enclosure 813788-001
Display enclosure 3D camera 832350-001
Miscellaneous parts
Component Spare part number
AC adapter:
AC adapter, 65-W, non-PFC, 4.5 mm 710412-001
AC adapter, 65-W, non-PFC, 4.5 mm EM 714657-001
AC adapter, 90-W, non-PFC, 4.5 mm 710413-001
AC adapter 120–W PFC S-3P Slim 4.5 mm 710415-001
Power cord (3-pin, black, 1.00-m):
For use in Denmark 755530-081
For use in Europe, the Middle East, and Africa 755530-021
For use in North America 755530-001
For use in the United Kingdom 755530-031
For use in Australia 755530-011
For use in Switzerland 755530-111
For use in Japan 755530-291
For use in People’s Republic of China 755530-AA1
For use in People’s Republic of China 755530-AA1
For use in South Korea 755530-AD1
For use in South Africa 755530-AR1
For use in India 755530-D61
Screw Kit 813683-001
HDMI to VGA Adapter 701943-001
Fingerprint reader board 818089-001
Fingerprint cable 818088-001
Microphone board 3D camera 832358-001
Miscellaneous parts 21
