HP ENVY Notebook Intel Models 17-n100 17-n199 3D camera Models 17-r100 17-r199 (worldwide) 3D camera Models m7-r100 m7-r199 (North America) - Maintenance and Service Guide

Bottom cover
Description Spare part number
Base enclosure 813783-001
Top cover with keyboard for use in the United States 813678-001
Top cover with keyboard for use in the United Kingdom 813678-031
For use in Belgium 813678-A41
For use in the Czech Republic and Slovakia 813678-FL1
For use in Denmark, Finland, and Norway 813678-DH1
For use in French Canada 813678-DB1
For use in France 813678-051
For use in Germany 813678-041
For use in Italy 813678-061
For use in the Netherlands 813678-B31
For use in Portugal 813678-131
For use in Russia 813678-251
For use in Saudi Arabia 813678-171
For use in Spain 813678-071
For use in Switzerland 813678-BG1
For use in Turkey 813678-141
For use in Japan 813678-291
For use in South Korea 813678-AD1
For use in Slovenia 813678-BA1
For use in Latin America 813678-161
For use in the United States black 818093-001
Before removing the bottom cover, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 27).
5. Remove the optical drive (see Optical drive on page 28).
Remove the bottom cover:
1. Remove the seven Phillips PM2.5×8.0 screws (1) and the two screws in the optical drive bay (2) that
secure the bottom cover to the computer.
Component replacement procedures 31
