Hard drive
Description Spare part number
750-GB, 5400-rpm, 9.5-mm 778190-005
1.0-TB, 5400-rpm, 9.5-mm 778192-005
1.0-TB hybrid, 5400-rpm, 9.5-mm 731999-005
2.0-TB, 5400-rpm, 9.5-mm 801808-005
Hard drive connector cable 813795-001
Hard Drive Hardware Kit 813796-001
Before removing the hard drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 27).
5. Remove the optical drive (see Optical drive on page 28).
6. Remove the bottom cover (see Bottom cover on page 31).
Remove the hard drive:
1. Disconnect the hard drive cable from the system board (1).
2. Remove the four Phillips PM2.5×3.0 screws (2) that secure the hard drive assembly to the computer.
