HP ENVY Notebook Intel Models 17-n100 17-n199 3D camera Models 17-r100 17-r199 (worldwide) 3D camera Models m7-r100 m7-r199 (North America) - Maintenance and Service Guide

3. Remove the system board (2) from the computer.
Reverse this procedure to install the system board.
Solid State Drive
Description Spare part number
256 GB mSATA solid-state drive 812708-001
512 GB mSATA solid-state drive 814224-001
512 GB M2 SATA-3 TLC 814224-001
512 GB M2 SATA-3 TLC Value 820547-001
Before removing the speakers, follow these steps:
Before removing the Speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 27).
5. Remove the optical drive (see Optical drive on page 28).
6. Remove the bottom cover (see Bottom cover on page 31).
●
Memory module (see Memory module on page 38)
●
Heat sink (see Heat sink on page 44)
Component replacement procedures 51
