Reverse this procedure to install the TouchPad.
Fingerprint reader board (select products only)
Description Spare part number
Fingerprint reader board 818089-001
Fingerprint reader cable 818088-001
Fingerprint reader bracket 818090-001
Before removing the Fingerprint reader board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 27).
5. Remove the optical drive (see Optical drive on page 28).
6. Remove the bottom cover (see Bottom cover on page 31).
7. Remove the hard drive (see Hard drive on page 34).
8. Remove the speakers (see Speakers (front) on page 47).
9. Remove the system board (see System board on page 49).
Remove the ngerprint reader board and cable:
1. Disconnect the ZIF connector cable (1) that secures the ngerprint reader to the top cover.
Component replacement procedures 57
