HP ENVY Notebook Intel Models 17-n100 17-n199 3D camera Models 17-r100 17-r199 (worldwide) 3D camera Models m7-r100 m7-r199 (North America) - Maintenance and Service Guide
Table Of Contents
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Component replacement procedures
- Bottom cover
- Hard drive
- WLAN module
- Memory module
- USB board
- Fan
- Heat sink
- RTC battery
- Speakers (front)
- Subwoofer
- System board
- Solid State Drive
- Speaker (rear)
- LID board
- TouchPad assembly
- Fingerprint reader board (select products only)
- Power connector cable
- Display assembly – touch screen
- Display assembly – non-touch screen
- Component replacement procedures
- Computer Setup (BIOS), TPM, and HP Sure Start – Windows 10
- Using Setup Utility (BIOS) in Windows 8.1
- Using Setup Utility (BIOS) in Windows 7
- HP PC Hardware Diagnostics (UEFI) – Windows 10
- Using HP PC Hardware Diagnostics (UEFI) in Windows 8.1
- Backup and recovery – Windows 10
- Backing up, restoring, and recovering in Windows 8.1
- Backing up, restoring, and recovering in Windows 7
- Ubuntu Linux – Backing up, restoring, and recovering
- Specifications
- Power cord set requirements
- Recycling
- Index
1 Product description
Category Description
Product Name HP ENVY Notebook
HP ENVY m7 Notebook (for 3D camera in North America — supporting models 17–r100 — 17–
r199)
3D camera Models 17-r100 17-r199 (worldwide)
Processors 6th generation Intel® Core™ i7 Processor
Intel Core i7-6700HQ (2.6 GHz, turbo up to 3.5 GHz), 1600 MHz/6 MB L3, Quad 45 W
Intel Core i7-6500U (2.5 GHz, turbo up to 3.1 GHz), 1600 MHz/3 MB L3, Dual 15 W
6th generation Intel Core i5 Processor
Intel Core i5-6200U (2.3 GHz, turbo up to 2.8 GHz), 1600 MHz/3 MB L3, Dual 15 W
5th generation Intel® Core™ i7 Processor
Intel Core i7-5500U (2.4 GHz, SC turbo up to 3.0 GHz), 1600 MHz/4 MB L3, Dual 15 W (models with
discrete graphics only)
5th generation Intel Core i5 Processor
Intel Core i5-5200U (2.2 GHz, SC turbo up to 2.7 GHz), 1600 MHz/3 MB L3, Dual 15 W
Chipset Intel HM170 Express Chipset (C-2 step), (supports Intel SKL H processor 2-chip BGA)
Integrated SoC (supports Intel SKL U processor 1-chip BGA)
Intel Wildcat Point-LP PCH (supports Intel BDW U processor 1-chip BGA)
Graphics Internal graphics:
Intel HD Graphics 530 (supports SKL H)
Intel HD Graphics 520 (supports SKL U)
Intel HD Graphics 5500 (supports BDW U)
Hybrid graphics:
●
VIDIA N16S-GT (GeForce 940M) with up to 2048 MB or 4096 MB of dedicated video memory
(256 Mx16 DDR3 900 MHz x 4 PCs, 1 GHz bridge to 900 MHz)
●
NVIDIA N16P-GT (GeForce GTX 950M) with 4096 MB of dedicated video memory (256 Mx16
DDR3L 900 MHz x 8 PCs, 1 GHz downgraded to 900 MHz)
Support HD Decode, DX11, and HDMI
Supports Optimus
Supports GPS (GPU Performance Scaling)
Panel
●
16:9 Ultra Wide Aspect Ratio (43.9-cm 17.3in), FHD, WLED, SVA, Antiglare (1920×1080) at
4.0 mm, typical brightness: UWVA, eDP300 nits (touch panel)
Flush glass panel cover support - antiglare panel for touch screens
Touch solution with ush glass, multitouch enabled
3D camera touch and non-touch panels are dierent
1
