Data Sheet

Datasheet | HP Elite x2 1012 G1
HP Elite x2 1012 G1 Specifications Table
Available Operating System
Windows 10 Pro 64
1
Windows 10 Home 64
1
Windows 10 Home Single Language 64
1
Processor Family
Intel® Core™ m7 processor; Intel® Core™ m5 processor; Intel® Core™ m3 processor
2
Available Processors
Intel® Core™ m5-6Y54 with Intel HD Graphics 515 (1.1 GHz, up to 2.7 GHz with Intel Turbo Boost Technology, 4 MB cache, 2 cores)
Intel® Core™ m3-6Y30 with Intel HD Graphics 515 (900 MHz, up to 2.2 GHz with Intel Turbo Boost Technology, 4 MB cache, 2 cores)
2
Chipset
Chipset is integrated with processor
Maximum Memory
8 GB LPDDR3-1866 SDRAM
(Transfer rates up to 1866 MT/s. Memory down dual channel (4 GB or 8 GB))
Internal Storage
128 GB up to 512 GB M.2 SATA SSD
3
180 GB or 256 GB M.2 SATA SED SSD
3
256 GB M.2 PCIe SSD
3
Display
12" diagonal FHD UWVA eDP ultra-slim LED-backlit touch screen (1920 x1280), direct bonded, Corning® Gorilla® Glass 4
6
Available Graphics
Integrated: Intel® HD Graphics 515
Audio
Audio by Bang & Olufsen; Dual stereo speakers; Dual microphone array
Wireless Technologies
Intel® Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo; Intel® Tri-Band Wireless-AC 18260 802.11a/b/g/n/ac
(2x2) and Bluetooth® 4.2 + WiGig Combo; HP hs3110 HSPA+ Mobile Broadband; HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband
Module
4,5
Communications
USB 3.0 to Gigabit adapter
Expansion Slots
1 microSD; 1 micro SIM (select models)
(Supports SD, SDHC, SDXC (microSD))
Ports and Connectors
1 USB Type-C™ with Thunderbolt™ support (docking, charging and USB 3.1); 1 USB Type-A (USB 3.0); 1 headphone/microphone combo
Input Device
HP Advanced Keyboard (with NFC and smartcard reader) (select models); HP Travel Keyboard (select models); ClickPad with on/off button,
supports 2-way scroll, taps and gestures enabled by default, two-finger scrolling, two finger zoom (pinch); HP Active Pen with Application Launch
Button with Wacom technology
Sensors
Accelerometer Magnetometer, Gyro (Combo chip) (tablet);Ambient light sensor (tablet); Proximity (SAR for WWAN) (tablet); NFC (advanced
keyboard); Dual Accelerometers (travel and advanced keyboard)
Camera
2 MP FHD 1080p front-facing webcam; 5 MP FHD 1080p rear-facing
6
Available Software
Buy Office; HP Support Assistant; HP ePrint; CyberLink Power DVD; Skype
7,8
Security Management
TPM 2.0; HP Fingerprint Reader (select models); Integrated smart card reader (advanced keyboard); Power-on Authentication (password,
fingerprint); Drive encryption pre-boot (password, fingerprint, select smart cards); HP BIOSphere with HP Sure Start; Absolute Persistence
Module; Microsoft Defender
12,13,14
Management Features
HP Touchpoint Manager (optional); HP Driver Packs; HP SoftPaq Download Manager (SDM); HP System Software Manager (SSM); HP BIOS Config
Utility (BCU); HP CIK for Microsoft SCCM; LANDESK Management
9,10,11
Power
45 W Smart USB Type-C™ AC adapter 4-cell, long life 40 WHr Li-ion polymer (tablet)
Dimensions
11.8 x 8.4 x 0.3 in (tablet); 11.8 x 8.4 x 0.5 in (tablet with travel keyboard); 11.8 x 8.4 x 0.6 in (tablet with advanced keyboard)
30 x 21.4 x 0.8 cm (tablet); 30 x 21.4 x 1.3 cm (tablet with travel keyboard); 30 x 21.4 x 1.6 cm (tablet with advanced keyboard)
Weight
Starting at 1.85 lb (tablet); Starting at 2.72 lb (tablet with travel keyboard); Starting at 2.89 lb (tablet with advanced keyboard)
Starting at 840 g (tablet); Starting at 1235 g (tablet with travel keyboard); Starting at 1310 g (tablet with advanced keyboard)
(Lowest weight configuration. Weight will vary by configuration. See QuickSpecs.)
Environmental
Low halogen
15
Energy Efficiency Compliance
ENERGY STAR® certified configurations available
2
