Installing and Configuring HSG Agent
4–4 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Figure 4–1: An example of a network connection
1
Agent system (has the Agent
software)
5
Hub or switch
2
TCP/IP Network
6
HSG80 controller and its
device subsystem
3
Client system (has the Client
software)
7
Servers
4
Fibre Channel cable
VTAT
O
VTAT
H-STATVCENTO O
VTAT
H-STATVCENTO O
CXO7240A
1
2
3
5
7
7
4 4
4
6
