Installing and Configuring HSG Agent
4–12 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Client system notification
options
Note: For all of the client
system notification
options, local notification is
available through an entry
in the system error log file
and Email (provided that
Email notification in
PAGEMAIL.COM has not
been disabled).
0 = No Error Notification−No error notification is
provided over network.
1 = Notification via a TCP/IP Socket
(Transmission Control Protocol/Internet
Protocol)−Updates the Storage Window of
subsystem changes provided AES is running.
Required for Windows NT event logging and
pager notification. If you do not select TCP/IP,
you will need to refresh the Storage Window to
obtain the latest status of a subsystem.
2 = Notification via the SNMP protocol (Simple
Network Management Protocol)–Requires you to
use an SNMP-monitoring program to view SNMP
traps.
3 = Notification via both TCP/IP and
SNMP–Combination of options 1 and 2.
Deleting a client system
entry
When you remove a client system from the
Agent’s list, you are instructing the Agent to stop
sending updates to that client system. In addition,
you will be unable to access this agent system
from the Navigation Tree.
Email notification Modify file pagemail.com in directory
sys$sysdevice:[swcc$agent].
When an error is logged, the Agent executes the
PAGEMAIL.COM command. You can modify this
file for Agent to log errors in a log file and/or
change the account to which Agent sends
messages. You can also modify for which level of
errors you will be notified. Client does not need to
be running to perform these actions.
Monitoring interval in
seconds
How often the subsystem is monitored.
Table 4–6: Information Needed to Configure Agent (Continued)
Term/Procedure Description
