Installing and Configuring HSG Agent
4–13HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
4–13
Removing the Agent
CAUTION: Do not uninstall the Agent if you want to preserve configuration
information. If you only want to install an upgrade, stop the Agent, and then install the
new version. Older versions will be automatically removed before the update, but all
configuration information will be preserved.
1. Enter the following and press the Enter key:
# setld -d SWCC520
The procedure to remove the Agent asks the following:
Are you sure you want to delete all Agent data?
2. Do one of the following:
— Select option y and then press the Enter key. All configuration files for the
Agent is deleted.
— Select option n and press the Enter key. The computer saves the configuration
data, which includes the following:
▲ Subsystem list of entries
▲ Client system access options
▲ Password
▲ Email notification
You are able to use the data if you reinstall the Agent or install a newer version of
the Agent.
Password It must be a text string that has 4 to 16
characters. It can be entered from the client
system to gain configuration access. Accessing
the SWCC Agent Configuration menu can
change it.
Table 4–6: Information Needed to Configure Agent (Continued)
Term/Procedure Description
