Using CLI for Configuration
6–7HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
6–7
RENAME !NEWCON02 RED2B2
SET RED2B2 OPERATING_SYSTEM=TRU64_UNIX
RENAME !NEWCON02 RED2A2
SET RED2A2 OPERATING_SYSTEM=TRU64_UNIX
SHOW CONNECTIONS
Connection
Name
Operating
System
Controlle
r
Port Address Status
Unit
Offset
!NEWCON0
2
TRU64_U
NIX
THIS 2 XXXXXX OL this 0
HOST_ID=XXXX-XXXX-XXXX-XX
XX
ADAPTER_ID=XXXX-XXXX-XXXX-XXX
X
!NEWCON0
3
TRU64_U
NIX
OTHER 2 XXXXXX OL other 0
HOST_ID=XXXX-XXXX-XXXX-XX
XX
ADAPTER_ID=XXXX-XXXX-XXXX-XXX
X
RED1A1 TRU64_U
NIX
OTHER 1 XXXXXX OL other 0
...
