SWCC Agent in TruCluster Environment
C–43HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
C–43
To verify that swcc was removed, use the ps command to determine if the steamd
daemon is running on the member. There should not be a steamd process.
# ps agx | grep steamd
540850 pts/1 S + 0:00.00 grep steamd
To start the CAA resource on another member, use the caa_start swcc command with
the -c option.
To verify that the swcc agent is accessible from the client, use the client running on a
PC to display information about the storage configuration. Make sure to use the
cluster alias when connecting from the client.
To fail over the CAA resource to another member of your choice, use the caa_relocate
swcc command with the -c option.
# caa_relocate swcc -c rye
Attempting to stop `swcc` on member `swiss`
Stop of `swcc` on member `swiss` succeeded.
Attempting to start `swcc` on member `rye`
Start of `swcc` on member `rye` succeeded.
# caa_stat swcc
NAME=swcc
TYPE=application
TARGET=ONLINE
STATE=ONLINE on rye
If you determine that the procedure was not successful, use the following table to
identify and solve problems. In this discussion, the active member is the member on
which you run the CAA resource.
Table C–3: Troubleshooting
Problem Possible Solutions
caa_stat command indicates
that the CAA resource is
offline
Use the caa_start swcc command interactively
to start the CAA resource.
steamd daemon is running on
multiple members
Use the caa_stat swcc to determine the
cluster member on which CAA is running the
resource. Then, use the ps command to
determine the process IDs of the steamd
daemon on the other members, and the kill
command to stop these processes.
