Planning Storage Configurations
2–11HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
2–11
Table 2–3: PTL addressing, single-bus configuration, six Model 4314R enclosures
Model 4314R Disk Enclosure Shelf 6 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 09 10 11 12 13 14 15
DISK
ID
Disk60000
Disk60100
Disk60200
Disk60300
Disk60400
Disk60500
Disk60800
Disk60900
Disk61000
Disk61100
Disk61200
Disk61300
Disk61400
Disk61500
Model 4314R Disk Enclosure Shelf 5 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 09 10 11 12 13 14 15
DISK
ID
Disk50000
Disk50100
Disk50200
Disk50300
Disk50400
Disk50500
Disk50800
Disk50900
Disk51000
Disk51100
Disk51200
Disk51300
Disk51400
Disk51500
Model 4314R Disk Enclosure Shelf 4 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 09 10 11 12 13 14 15
DISK
ID
Disk40000
Disk40100
Disk40200
Disk40300
Disk40400
Disk40500
Disk40800
Disk40900
Disk41000
Disk41100
Disk41200
Disk41300
Disk41400
Disk41500
Model 4314R Disk Enclosure Shelf 1 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 09 10 11 12 13 14 15
DISK
ID
Disk10000
Disk10100
Disk10200
Disk10300
Disk10400
Disk10500
Disk10800
Disk10900
Disk11000
Disk11100
Disk11200
Disk11300
Disk11400
Disk11500
