Preparing the Host System
3–5HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
3–5
Figure 3–2: Single-Bus Enterprise Storage RAID Array Storage System
1 SCSI Bus 1 Cable 2 SCSI Bus 2 Cable
3 SCSI Bus 3 Cable 4 SCSI Bus 4 Cable
5 SCSI Bus 5 Cable 6 SCSI Bus 6 Cable
7 AC Power Inputs 8 Fibre Channel Ports
1
8
2
3
6
CXO7382A
4
5
7
