HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
![](/manual/hp/vmware-view-premier-starter-kit-10-license-no-media-software/hp-insight-management-wbem-providers-snmp-data-migration-for-vsphere-51-u2-september-2013/images/img-118.png)
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.1
MIB OID Name
cpqHeResMemBoardSlotIndex
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.2
MIB OID Name
cpqHeResMemBoardOnlineStatus
WBEM Class and Property
SMX_MemoryBoard.OperationalStatus
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.3
MIB OID Name
cpqHeResMemBoardErrorStatus
WBEM Class and Property
SMX_MemoryBoard.OperationalStatus
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.4
MIB OID Name
cpqHeResMemBoardLocked
WBEM Class and Property
SMX_MemoryBoard.Locked
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.5
MIB OID Name
cpqHeResMemBoardNumSockets
WBEM Class and Property
SMX_MemoryBoard.NumberOfSockets
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.6
MIB OID Name
cpqHeResMemBoardOsMemSize
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.6.2.14.10.1.7
MIB OID Name
cpqHeResMemBoardTotalMemSize
WBEM Class and Property
SMX_MemoryBoard.TotalMemory
