MIB OID Name
cpqDaSpareReplacedDrvBusNumber
WBEM Class and Property
SMX_SADiskDriveLocation. PhysicalPosition
Notes
By association traversal via
SMX_SpareExtentStorageExtent
MIB OID
1.3.6.1.4.1.232.3.2.4.1.1.10
MIB OID Name
cpqDaSpareReplacedDrvBay
WBEM Class and Property
SMX_SADiskDriveLocation. PhysicalPosition
Notes
Location of actual drive and spare drive both are specified
by SMX_SADiskDriveLocation. PhysicalPosition
. Whether
the drive is spare drive can be identified by
SMX_SADiskDrive.DriveConfiguration.
MIB OID
1.3.6.1.4.1.232.3.2.4.1.1.11
MIB OID Name
cpqDaSparePercentRebuild
WBEM Class and Property
SMX_SAStorageVolume.PercentComplete
Notes
MIB OID
1.3.6.1.4.1.232.3.2.5.1
MIB OID Name
cpqDaPhyDrvTable
WBEM Class and Property
Notes
MIB OID
1.3.6.1.4.1.232.3.2.5.1.1
MIB OID Name
cpqDaPhyDrvEntry
WBEM Class and Property
Notes
MIB OID
1.3.6.1.4.1.232.3.2.5.1.1.1
MIB OID Name
cpqDaPhyDrvCntlrIndex
WBEM Class and Property
Notes
MIB OID
1.3.6.1.4.1.232.3.2.5.1.1.2
MIB OID Name
cpqDaPhyDrvIndex
