MIB OID Name
cpqSsBoxSerialNumber
WBEM Class and Property
SMX_SADriveCage.SerialNumber
SMX_SASDriveCage.SerialNumber
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.18
MIB OID Name
cpqSsBoxCntlrHwLocation
WBEM Class and
Property
SMX_SAStorageEnclosureLocation.LocationInformation/LocationInfoDesc
SMX_SASStorageEnclosureLocation.LocationInformation/LocationInfoDesc
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.19
MIB OID Name
cpqSsBoxBackplaneSpeed
WBEM Class and Property
SMX_SADriveCage.BackplaneSpeed
SMX_SASDriveCage.BackplaceSpeed
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.20
MIB OID Name
cpqSsBoxConnectionType
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.21
MIB OID Name
cpqSsBoxHostConnector
WBEM Class and Property
SMX_SAArraySystemStorageEnclosureProcessor
SMX_SASArraySystemStorageEnclosureProcessor
Notes
Via association traversal
MIB OID
1.3.6.1.4.1.232.8.2.1.1.22
MIB OID Name
cpqSsBoxBoxOnConnector
WBEM Class and Property
SMX_SAStorageEnclosureLocation.PhysicalPosition
SMX_SASStorageEnclosureLocation.PhysicalPosition
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.23
MIB OID Name
cpqSsBoxLocationString
