![](/manual/hp/vmware-virtualcenter-management-server-license-software/p00105-hp-base-server-profile/images/img-16.png)
18 Version 1.5.1
system1:
HP_ComputerSystem:
chassis1:
HP_ComputerSystemChassis
proc1: HP_Processor
proc2: HP_Processor
HP_SystemProcessor
HP_ComputerSystemPackage
fan1: HP_Fan
fan2: HP_Fan
fan3: HP_Fan
HP_SystemFan
prof3: CIM_RegisteredProfile
RegisteredOrg: DMTF (2)
RegisteredName: Base Server
prof2: CIM_RegisteredProfile
RegisteredOrg: DMTF (2)
RegisteredName: Physical Asset
prof1: CIM_RegisteredProfile
RegisteredOrg: DMTF
RegisteredName: Fan
prof4: HP_RegisteredProfile
RegisteredOrg: Other (1)
OtherRegOrg:HP WBEM TC
RegisteredName: HP Base Server
prof5: HP_RegisteredProfile
RegisteredOrg: Other (1)
OtherRegOrg: HP WBEM TC
RegisteredName: HP Base Server
Physical Asset
HP_ExtendsProfile
prof6: HP_RegisteredProfile
RegisteredOrg: Other (1)
OtherRegOrg: HP WBEM TC
RegisteredName: HP Fan
HP_ExtendsProfile
Interop Namespace
CIM_ReferencedProfile
CIM_ReferencedProfile
prof7: HP_RegisteredProfile
RegisteredOrg: Other (1)
OtherRegOrg: HP WBEM TC
RegisteredName: HP CPU
prof8: CIM_RegisteredProfile
RegisteredOrg: DMTF
RegisteredName: CPU
CIM_ReferencedProfile
HP_ExtendsProfile
HP_ExtendsProfile
CIM_ElementConformsToProfile
Figure 2 – HP Base Server Profile: Base System with Fans and Processors
Figure 3 shows a system containing 1 memory module and 1 CPU. The system also contains 2 memory
board slots. The physical side of the CPU, Memory, and Base server models have been implemented.
HP_ComputerSystem is associated with its physical chassis (HP_ComputerSystemChassis) via the
association instance HP_ComputerSystemPackage. HP_Memory and HP_Processor have associations
to their physical model via realizes associations (HP_RealizesMemory and HP_RealizesProcessor
respectively).
The single memory module (HP_PhysicalMemory) is installed on a memory board, shown here as an
instance of HP_PhysicalMemory associated with HP_MemoryBoard via an HP_ModuleOnBoard
association. The memory board is in turn associated with the slot it is installed in, shown as an instance
of HP_MemoryBoardInSlot associating HP_MemoryBoard and CIM_Slot.
