Top components
Pointing devices
Component Description
(1) TouchPad Moves the pointer and selects or activates items on the screen.
(2) Left TouchPad button Functions like the left button on an external mouse.
(3) TouchPad scroll zone Scrolls up or down.
(4) Right TouchPad button Functions like the right button on an external mouse.
