To force the printer to accept a cartridge, you can tap , , , on the front panel.
1. Install the cartridge in the printer (see Insert an ink cartridge on page 110).
2. The front panel noties you that the cartridge is altered, and the cartridge removal process will start. If you
believe that you purchased a non-Original HP cartridge, HP recommends that you abort the process. To
check the authenticity of your cartridges, see http://www.hp.com/go/anticounterfeit.
3. If you proceed, the front panel displays a series of warning messages.
NOTE: The printer detects cartridges that are non-Original HP. The printer is only intended to be used with
cartridges using an HP original chip. Cartridges using a non-HP chip may not work, and those that work today
may not work in the future. More at: http://www.hp.com/go/learnaboutsupplies.
When the process is nished, the front panel will give the usual ink cartridge display but the cartridge will not
report the ink level.
About the printheads
The printheads are connected to the ink cartridges and jet ink onto the paper.
CAUTION: Observe precautions when handling printheads because they are ESD-sensitive devices (see the
Glossary on page 175). Avoid touching pins, leads and circuitry.
Check the printhead status
The printer automatically checks and services the printheads after each print. Follow the steps below to get more
information on your printheads.
1. From the front panel, tap , then tap the printhead on which you want information.
2. The front panel displays:
● Colors
● Product name
● Product number
● Serial number
● Status, see Front-panel error messages on page 167
● Volume of ink it has used
● Warranty status
You can also get most of this information from the HP DesignJet Utility. In the HP DesignJet Utility for Windows,
go to the Overview tab, then the Supplies tab.
For an explanation of the printhead status messages, see Printhead status messages on page 162.
If the warranty status is See warranty note, this indicates that non-HP ink is being used. See the Legal
Information document provided with your printer for details of the warranty implications.
112 Chapter 11 Handling ink cartridges and printheads ENWW
