Remove a printhead
CAUTION: Make sure the printer wheels are locked (the brake lever is pressed down) to prevent the printer from
moving.
CAUTION: Printhead replacement must be performed with the printer powered on.
1. From the front panel, tap , then Printheads, then , then Replace.
2. The printer moves the carriage into the correct position.
CAUTION: If the carriage is left in the removal position for more than three minutes without inserting or
removing any printheads, it tries to move back to its normal position in the right-hand end.
3. When the carriage has stopped moving, the front-panel display asks you to open the window.
4. Locate the carriage on the right side of the printer.
5. Pull the handle up and toward you to release the wire loop.
ENWW Remove a printhead 113
