10. Pull the blue handle upward until the printhead is released from the carriage.
CAUTION: Do not pull abruptly because this can damage the printhead.
11. The front-panel display identies the missing printhead.
Insert a printhead
NOTE: You cannot insert a new printhead successfully if either of the connected ink cartridges is empty, or
nearly empty. In this case, you should replace the ink cartridge before inserting the new printhead.
1. Remove the orange protective caps by pulling them down.
ENWW Insert a printhead 115
