● (E) indicates papers available in Europe, the Middle East and Africa
● (J) indicates papers available in Japan
● (L) indicates papers available in Latin America
●
(N) indicates papers available in North America
If the part number is not followed by parentheses, the paper is available in all regions.
Roll paper
Paper type g/m² Length Width Product number
HP Bond and Coated Paper
HP Super Heavyweight Plus Matte
Paper
210 30.4 m (100 ft) 610 mm (24 in) Q6626B
914 mm (36 in) Q6627B
1066 mm (42 in) Q6628B
HP Universal Bond Paper 80 45.7 m (150 ft) 419 mm (16.5 in) (A2) Q1446A (EJ)
594 mm (23.39 in) (A1) Q8003A (AJ)
SA089A (2 Pack) (J)
610 mm (24 in) Q1396A
SA025A (2 Pack) (J)
914 mm (36 in) Q1397A
1066 mm (42 in) Q1398A
1117 mm (44 in) 2NC45A
91.4 m (300 ft) 594 mm (23.39 in) (A1) Q8004A (EAJ)
840 mm (33.11 in) (A0) Q8005A (EAJ)
174.9 m (574 ft) 914 mm (36 in) Q8751A (ELN)
HP Bright White Inkjet Paper 90 45.7 m (150 ft) 419 mm (16.5 in) Q1446A (EJ)
594 mm (23.4 in) (A1) Q1445A (EJ)
610 mm (24 in) C1860A (LN)
610 mm (24 in) C6035A (EAJ)
840 mm (33.11 in) (A0) Q1444A (EAJ)
914 mm (36 in) C6036A (EAJ)
914 mm (36 in) C1861A (LN)
91.4 m (300 ft) 914 mm (36 in) C6810A
HP Heavyweight Coated Paper 130 30.4 m (100 ft) 610 mm (24 in) C6029C
914 mm (36 in) C6030C
1066 mm (42 in) C6569C
67.5 m (225 ft) 1066 mm (42 in) Q1956A (ELN)
HP Coated Paper 90 45.7 m (150 ft) 419 mm (16.54 in) (A2) Q1443A (J)
594 mm (23.4 in) (A1) Q1442A (AEJ)
610 mm (24 in) C6019B
