Roll paper (continued)
Paper type g/m² Length Width Product number
60.9 m (200 ft) 1066 mm (42 in) Q8755A (AELN)
HP Premium Matte Photo Paper 210 30.4 m (100 ft) 610 mm (24 in) CG459B
914 mm (36 in) CG460B
HP Backlit Material
HP Premium Vivid Color Backlit Film 285 30.4 m (100 ft) 914 mm (36 in) Q8747A
1066 mm (42 in) Q8748A (AELN)
HP Self-Adhesive Material
HP Everyday Adhesive Matte
Polypropylene
120
168 with
liner
22.8 m (75 ft) 610 mm (24 in) C0F18A (AELN)
914 mm (36 in) C0F19A (AELN)
1066 mm (42 in) C0F20A (AELN)
HP Everyday Adhesive Gloss
Polypropylene
140
190 with
liner
22.8 m (75 ft) 914 mm (36 in) C0F28A (AELN)
1066 mm (42 in) C0F29A (AELN)
HP Universal Adhesive Vinyl 160
300 with
liner
20 m (66 ft) 610 mm (24 in) W4Y93A (ELN)
914 mm (36 in) C2T51B (2 Pack) (ELN)
1066 mm (42 in) C2T52B (2 Pack) (ELN)
HP Banner and Sign Material
HP Everyday Matte Polypropylene 120 30.4 m (100 ft) 610 mm (24 in) CH022A (AELN)
914 mm (36 in) CH023A (AELN)
1066 mm (42 in) CH025A
60.9 m (200 ft) 914 mm (36 in) CH024A (AELN)
Order other accessories
The following accessories can be ordered for your printer.
Name Product number
HP DesignJet PostScript/PDF Upgrade Kit C0C66B
HP DesignJet 44-inch Roll Feed Spindle Q6709B
HP DesignJet 3-in Spindle Adaptor Kit CN538A
HP SD Pro 44-in Scanner C6H50B
HP HD Pro 42-in Scanner G6H51B
HP USB 3.0 to Gigabit LAN Adapter N7P47AA
128 Chapter 13 Accessories ENWW
