4. Carefully remove any of the jammed paper that you can lift up and out from the top of the printer.
CAUTION: Do not move the paper sideways, as it could damage the printer.
5. Rewind the roll.
6. If the paper is stuck and cannot be rewound further, cut it from the roll.
