If the problem persists despite all the above actions, contact your customer service representative for further
support.
Whole image is blurry or grainy
1. Check that the paper type you have loaded corresponds to the paper type selected in the front panel and in
your software. See View information about the paper on page 33.
2. Check that you are printing on the correct side of the paper.
3. Check that you are using appropriate print-quality settings (see Printing on page 49). In some cases, you
can overcome a print-quality problem merely by selecting a higher print-quality level. For instance, if you
have set the Print Quality slider to Speed, try setting it to Quality. If you change the print-quality settings,
you may wish to reprint your job at this point in case the problem has been solved.
4. Realign the printheads. See Align the printheads on page 160. After alignment, you may wish to reprint
your job in case the problem has been solved.
5. Clean the printhead drop detector. See Clean the printhead drop detector on page 158.
6.
Go to the front panel and tap , then Paper advance calibration. Choose the paper source and then
Paper advance calibration. See Recalibrate the paper advance on page 139.
If the problem persists despite all the above actions, contact your customer service representative for further
support.
