Cannot insert an ink cartridge
1. Check that you have the correct type of cartridge (model number).
2. Check that the colored label on the cartridge is the same color as the label on the slot.
3. Check that the cartridge is correctly oriented, with the letter or letters marking the cartridge label right-side
up and readable.
CAUTION: Never clean inside the ink cartridge slots.
Ink cartridge status messages
These are the possible ink cartridge status messages:
● OK: The cartridge is working normally, with no known problems.
● Missing: There is no cartridge present, or it is not correctly connected to the printer.
● Low: The ink level is low.
● Very low: The ink level is very low.
● Empty: The cartridge is empty.
● Reseat: You are recommended to remove the cartridge and then reinsert it.
● Replace: You are recommended to replace the cartridge with a new cartridge.
● Expired: It is past the cartridge's expiration date.
● Non-HP: The cartridge contains ink not made by HP.
● Wrong: The cartridge family or model is wrong, or it has been inserted wrongly.
● Altered: The cartridge has been altered (relled).
Cannot insert a printhead
1. Check that you have the correct type of printhead (model number).
2. Check that you have removed the two orange protective caps from the printhead.
3. Check that the printhead is correctly oriented (compare with the others).
4. Check that you have correctly closed and latched the printhead cover, see Insert a printhead on page 115.
Front panel recommends reseating or replacing a printhead
1. From the front panel, turn the power o then on.
2. Check the front-panel display message, if it shows the ready message, the printer is ready to print. If the
problem remains continue with the next step.
3. Remove the printhead, see Remove a printhead on page 113.
156 Chapter 16 Troubleshooting ink cartridge and printhead issues ENWW
