Introduction
HP Customer Care oers award-winning support to ensure you get the most from your HP DesignJet, providing
comprehensive, proven support expertise and new technologies to give you unique end-to-end support. Services
include setup and installation, troubleshooting tools, warranty upgrades, repair and exchange services, phone
and Web support, software updates and self-maintenance services. To nd out more about HP Customer Care,
see Contact HP Support on page 170.
To register your warranty, visit http://register.hp.com/.
HP Professional Services
HP Support Center
Enjoy a world of dedicated services and resources to ensure you always get the best performance from your
HP DesignJet printers and solutions.
Join the HP community at the HP Support Center, your large-format printing community, for 24×7 access to:
● Multimedia tutorials
● Step-by-step how-to guides
● Downloads: the latest printer rmware, drivers, software, paper presets, etc.
● Technical support: online troubleshooting, customer care contacts and more
● Workows and detailed advice for completing various printing tasks from particular software applications
● Forums for direct contact with the experts, both HP and your colleagues
● Warranty tracking online, for your peace of mind
● Latest product information: printers, supplies, accessories, software, etc.
● Supplies Center for all you need to know about ink and paper
The HP Support Center can be found at http://www.hp.com/go/T1700/support.
By customizing your registration for the products you have purchased and your type of business, and by setting
your communication preferences, you decide the information you need.
Download printer software
Install the printer software from http://www.hp.com/go/T1700/drivers. Be sure to follow the software
installation instructions.
HP Care Packs and Warranty Extensions
HP Care Packs and Warranty Extensions allow you to extend your printer's warranty beyond the standard period.
They include remote support. On-site service is also provided if necessary, with two alternative response-time
options:
● Next business day
● Same business day, within four hours (may not be available in all countries)
There is an HP Installation service that unpacks, sets up, and connects the printer for you.
For more information on HP Care Packs, see http://cpc.ext.hp.com/portal/site/cpc.
ENWW Introduction 169
