Functional specications
HP ink supplies
Printheads Universal printheads, which can be inserted into any of the available slots. Once initialized in
a particular slot, they cannot be moved to another.
Ink cartridges Cartridges containing 130 ml of ink: matte black, photo black, light gray, cyan, magenta,
yellow
Cartridges containing 300 ml of ink: matte black, photo black, light gray, cyan, magenta,
yellow
Paper sizes
Minimum Maximum
Roll width 279 mm (11 in) 1118 mm (44 in)
Roll length 91 m (300 feet)
Roll diameter 135 mm (5.3 in)
Roll weight 11.9 kg (26.3 lb)
Sheet width 210 mm (8.26 in) 1118 mm (44 in)
Sheet length 279 mm (11 in) 1676 mm (66 in)
Paper thickness 0.5 mm (19.68 mil)
Paper weight 60 g/m² 328 g/m²
Printing resolutions
Self-adhesive material, banner, backlit, glossy
paper Coated, bond, lm, technical
Print quality
Maximum
detail
Rendering resolution
(ppi)
Printing resolution
(dpi)
Rendering resolution
(ppi)
Printing resolution
(dpi)
Best On
O
1200 × 1200
600 × 600
2400 × 1200
1200 × 1200
600 × 600 1200 × 1200
Normal On/O 600 × 600 1200 × 1200 600 × 600 1200 × 1200
Fast On/O – – 600 × 600 1200 × 1200
Economode On/O – – 300 × 300 600 × 1200
Margins
Top, right and left margins 3 mm (0.1 in) (default)
5 mm (0.2 in) (optional)
Bottom margin (trailing edge) 3 mm (0.1 in) (roll, default)
5 mm (0.2 in) (roll, optional)
17 mm (0.67 in) (sheet)
