Mechanical accuracy
±0.1% of the specied vector length or ±0.2 mm (whichever is greater) at 23°C (73°F), 50-60% relative humidity, on E/A0 printing material
in Best or Normal mode with HP Matte Film roll feed.
Graphic languages supported
HP DesignJet Languages
T1700, T1700dr HP-PCL3GUI, HP-GL/2, CALS G4, TIFF, JPEG
T1700 PS, T1700dr PS HP-PCL3GUI, HP-GL/2, CALS G4, TIFF, JPEG, Adobe PDF 1.7 ext. 3, Adobe PostScript 3
Physical specications
Printer physical specications
T1700 T1700dr
Weight 88.9 kg (196 lb) 89.4 kg (197.1 lb)
Width 1802 mm (70.9 in)
Depth 695 mm (27.4 in)
Height 997 mm (39.3 in)
The depth is measured without the upper spindle; wall spacers up; ink cover opened; roll covers and basket
closed.
Memory specications
Memory
specications
Virtual memory 128 GB
Hard disk 500 GB
Power specications
Printer power
specications
Input voltage 100–240 V ac ±10%, auto-ranging
Frequency 50/60 Hz
Maximum current 2 A
Power 100 W
Ecological specications
This product complies with the WEEE Directive 2012/19/EU and RoHS Directive 2011/65/EU. To determine the
ENERGY STAR and EPEAT registration status of your product model, see http://www.hp.com/go/ecolabels.
