Before requesting a demo print, check that the printer and the paper are ready for printing.
● The loaded paper should be at least A3 landscape—419 mm (16.53 in) wide—otherwise the print may be
clipped.
● The front panel should be displaying the Ready message.
To print a demo print, tap , then scroll down and tap Internal prints, then Demo prints, and select a print.
The following prints are available:
● Render
● CAD black & white
● GIS
Congure your printer
Connect the printer to your network
The printer is able to congure itself automatically for most networks, in a similar way to any computer in the
same network. The rst time you connect it to a network, this process may take a few minutes.
Once the printer has a working network conguration, you can check its network address from the front panel:
tap
.
TIP: Consider making a note of the printer’s IP address, because you may need it during the setup process of
connecting your Windows or Mac OS computer clients.
Modify network conguration
To modify the current network conguration, go to the front panel and tap , then , then Network >
Gigabit Ethernet. From here it is possible, though not normally necessary, to change the settings manually; this
can also be done remotely using the Embedded Web Server.
For full details of the available connectivity settings, see Networking on page 41.
If you accidentally miscongure the printer’s network settings, you can restore the network settings to their
factory values from the front panel: tap
, then Network > Restore factory settings. Then you must restart
the printer. This automatically provides a working network conguration for most networks. The printer’s other
settings remain unchanged.
ENWW Congure your printer 15
