9. Roll the paper into the printer until you feel resistance and the paper exes slightly. When the printer
detects the paper, it beeps, then feeds it in automatically.
10. If the leading edge of the paper has a barcode, the printer reads and then cuts o the barcode; you should
remove and discard the cut strip of paper.
11. If the leading edge of the paper has no barcode, the front panel prompts you to select the paper category
and type.
TIP: If you have loaded a paper type whose name does not appear in the paper list, see Paper type is not
in the driver on page 132.
12. If the Printing paper info option is enabled, the front panel may ask you to specify the length of the roll. See
Printing paper info on page 35.
13. The printer checks the alignment and measures the width, then the front panel prompts you to close the
roll cover.
If the paper is not correctly aligned, the printer automatically proceeds to realign it.
NOTE: If you have an unexpected issue at any stage of the paper loading process, see Paper cannot be loaded
successfully on page 131.
Unload a roll
Before unloading a roll, check whether there is paper on the roll or if the roll is out of paper, and follow the
appropriate procedure as described below.
Quick procedure with paper on the roll
If there is paper on the roll, just open the roll cover, and the roll is unloaded automatically.
NOTE: When the roll is unloaded in this way, no barcode is printed on it, so the printer will not know the length
of the roll when it is next loaded. See Printing paper info on page 35.
NOTE: If you open the cover of any roll while a sheet is loaded, the sheet is also unloaded.
Front panel procedure with paper on the roll
If there is paper on the roll, you can unload it from the front panel.
1. Tap , then the roll icon, then Unload.
2. You may need to open the roll cover.
