Roll out of paper procedure
If the end of the paper is no longer attached to the core, pull out the paper from the printer.
Pull from wherever the paper is accessible; the rear of the printer is recommended. You may need to open the
roll cover.
Load a single sheet
1. Ensure that all roll covers are closed. If any cover is opened while a sheet is loaded, the sheet will be
immediately unloaded.
2. On the front panel, tap , then Sheet > Load.
3. Select your paper category and type.
TIP: If you have loaded a paper type whose name does not appear in the paper list, see Paper type is not
in the driver on page 132.
4. T1700dr only: If a roll is already loaded, you have to wait while it is withdrawn to the standby position; it can
be printed on again without reloading as soon as the sheet paper has been unloaded.
NOTE: On dual-roll models, if at any time you open a roll cover while that roll is in the standby position,
the roll will be automatically unloaded, and you will have to reload it the next time you want to print on it.
5. When prompted by the front panel, insert the sheet into the cut-sheet slot on the right-hand side of the
printer. The side to be printed is facing us in the illustrations; it will be facing up within the printer.
Load your sheet aligned with the load line and insert until the paper will not continue; with thicker sheets,
you feel resistance.
WARNING! Do not push your ngers inside the printer's paper path.
6. Tap the OK key on the front panel to feed the paper into the printer. Guide the sheet into the printer; this is
especially important with thicker papers.
7. The printer checks the alignment and measures the sheet.
