You can export the new paper preset to your computer and use it on other HP DesignJet T1700 series printers. In
the Color Center, select Paper Preset Management, select the paper preset, and tap at the bottom of the page.
Then follow the instructions on the screen. To install the preset on another printer, see To install a downloaded
paper preset on page 33.
Printing paper info
Enable the Printing paper info option to record the printer’s estimate of the remaining roll length, paper width
and type. The information is a combination of barcode and text that is printed on the leading edge of the roll
when the paper is unloaded from the printer.
NOTE: The paper-length estimate is available only if the printer registered the amount of paper that was on the
roll when you loaded it. To provide this information to the printer, specify the roll length on the front panel when
loading the paper, or load a roll that has the paper-data barcode printed on it.
NOTE: The barcode and text are printed on the roll only when the loading and unloading processes are started
from the front panel's Paper menu.
NOTE: This option can be expected to work only with papers that are completely opaque: it may fail with
transparent or translucent papers.
To enable the Printing paper info option, go to the front panel and tap , then Paper source > Printing
paper info > Enable.
NOTE: Enabling this option slightly changes the paper loading and unloading procedures.
Move the paper
If the printer is idle (ready to print), you can move the paper forwards or backwards from the front panel. You
may want to do this in order to have more or less white space between the last print and the next one.
To move the paper, tap , then Paper source > Move paper.
Tap the up arrow to advance the paper and the down arrow to rewind it.
Maintain paper
To maintain paper quality, follow the recommendations below.
● Store rolls covered by another piece of paper or cloth
● Store cut sheets covered and clean or brush them before loading them in the printer
● Clean input and output platens
● Always keep the window of your printer closed
NOTE: Photo and coated paper requires careful handling, see Print is scued or scratched on page 144.
