CAUTION: Remove the cut piece from the output tray. If strips or short prints are left in the output tray the
printer could jam.
NOTE: Photo and coated paper requires careful handling, see Print is scued or scratched on page 144.
TIP: To move the paper without cutting it, see Move the paper on page 35.
ENWW Feed and cut the paper 37
